CORE_ARCHITECTURE
The Lane-based Gateway
Clawdbot is essentially a TypeScript CLI Application, not a Web App. It runs as a daemon on your machine, acting as a gateway for all external connections (Telegram, Slack, etc.).
The core architecture uses the "Lane-based" design pattern:
- Channel Adapter: Standardizes message input from different channels.
- Gateway Server: Task coordination center handling concurrent requests.
- Lane Queue: Default to Serial. Each session is assigned a dedicated lane, avoiding the race condition hell of async/await. Only explicitly low-risk tasks are processed in parallel.
// Gateway Coordinator
class Gateway {
// Map session ID to dedicated Serial Lane
private lanes = new Map<string, SerialLane>();
async handleRequest(req: Request) {
const lane = this.lanes.get(req.sessionId)
|| new SerialLane();
// High-risk/Stateful -> Serial Lane (Queue)
if (req.isStateful) {
await lane.add(new Task(req));
}
// Low-risk/Read-only -> Parallel execution
else {
await runParallel(new Task(req));
}
}
}
// Serial Lane: Prevents race conditions
class SerialLane {
private queue: Task[] = [];
private isRunning = false;
async add(task: Task) {
this.queue.push(task);
if (!this.isRunning) this.process();
}
private async process() {
this.isRunning = true;
while (this.queue.length > 0) {
// Execute one by one
await this.queue.shift()?.execute();
}
this.isRunning = false;
}
}MEMORY_SYSTEM
Hybrid Retrieval Architecture
Without memory, AI is just a goldfish. Clawdbot solves persistence via a dual-layer system:
- Session Transcripts (JSONL): Records full session history for context building.
- Memory Files (Markdown): Long-term memory stored in
memory/*.md.
Hybrid Search
Combines Vector Search (SQLite) and Keyword Search (FTS5). Searching for "authentication bug" finds semantically related "auth issues" and matches exact phrases. The Agent manages memory directly via standard file writing tools, no black-box API.
// Memory Structure
memory/
├── user_profile.md
├── project_claudia.md
└── tech_stack_notes.md
// Search Query
SELECT * FROM memory
WHERE vec_search(embedding, query)
OR text_match(content, query);COMPUTER_USE
Sandboxed Execution
Clawdbot gives Agents real computer operation permissions, but with strict security limits:
- Execution Environment: Defaults to Docker Sandbox, can also be configured for direct host operation.
- Allowlist: User explicitly approved commands (e.g., npm, git).
- Blocklist: Defaults to blocking dangerous operations (e.g.,
rm -rf /, command substitution, redirection to system files).
// ~/.clawdbot/exec-approvals.json
{
"allowlist": [
{ "pattern": "/usr/bin/npm", "lastUsed": 1706644800 },
{ "pattern": "/opt/homebrew/bin/git", "lastUsed": 1706644900 }
],
"blocked": [
"rm -rf /",
"cat file > /etc/hosts"
]
}SEMANTIC_VISION
Accessibility Tree over Pixels
Browser tools do not rely on screenshots, but use Semantic Snapshots.
It is a text representation of the page's Accessibility Tree (ARIA).
Browsing the web is essentially a semantic understanding task, not just a visual task. The Agent sees a structured list of buttons, inputs, and headings.
- button "Sign In" [ref=1]
- textbox "Email" [ref=2]
- textbox "Password" [ref=3]
- link "Forgot password?" [ref=4]
- heading "Welcome back"
